Hose Reel - Heavy Duty; Maximum Hose Length 15.2 m | 50 ft; Hose Inside Diameter 9.5 mm | 0.375 in;Reel Diameter 425.5 mm | 16.750 in; Hose End 1/4 NPT Male
Hose is plumbed into the base to eliminate the risk of stress on the swivel. The reliable speed latch allows for positive locking of the spool in 2 positions per rotation. All steel components are powder coated for maximum corrosion resistance. Manufacturer Part Number: 5650 OLP
Request a quote
For large volumes and customised products, add to your cart and click request a quote, orcontact usand we will respond within 2 working days.
Specifications
Imperial
Metric
| Brand | Reelcraft |
|---|---|
| Manufacturer Part Number | 5650 OLP |
| Type | Heavy Duty |
| Maximum Hose Length | 50 ft |
| Includes | 50 ft Hose |
| Maximum Operating Pressure | 300 PSI |
| Maximum Operating Temperature | 150 °F |
| Reel Diameter | 16.750 in |
| Hose Inside Diameter | 0.375 in |
| Hose Outside Diameter | 0.600 in |
| Hose End | 1/4 NPT Male |
| Inlet Thread Size | 3/8 NPT Female |
| Outlet Thread Size | 1/4 NPT Female |
| Overall Height | 17.625 in |
| Overall Width | 5.875 in |
| Color | Red |
| Material | Steel |
| Special Offer | New |
