Quantity | Unit price |
---|---|
1 + | $12.78 |
For large volumes and customised products, add to your cart and click request a quote, orcontact usand we will respond within 2 working days.
Base Style | Rectangular |
---|---|
Face Type | Flat Face w/Tang |
Initial End Force | 1 kg |
Initial End Force | 2.25 lbs |
Final End Force | 11.7 kg |
Final End Force | 25.75 lbs |
Stroke Length | 4.8 mm |
Stroke Length | 0.19 in |
Base Height | 6.4 mm |
Base Height | 0.250 in |
Base Length | 25.4 mm |
Base Length | 1.00 in |
Base Width | 38.1 mm |
Base Width | 1.50 in |
Base Width Center to Center | 28.7 mm |
Base Width Center to Center | 28.7 mm |
Face Width | 22.4 mm |
Face Width | 0.880 in |
Face Length | 0.250 in |
Face Length | 0.250 in |
Face Material | Steel |
Height to Plunger Center | 7.9 mm |
Height to Plunger Center | 7.9 mm |
Body Material | Aluminum |
Hole Size | 5.1 mm |
Hole Size | 0.20 in |
